Zoo Keeper Bike
Himiway B3
Himiway B3
Regular price
$1,400.00 USD
Regular price
$1,600.00 USD
Sale price
$1,400.00 USD
Unit price
/
per
Couldn't load pickup availability
Recommended Height: 5'~6'
-
A – total length63.8
-
B - handlebar height45.3
-
C – wheelbase42.5
-
D – minimum seat height31.5
-
E – maximum seat height39.5
-
F – chain stay length15.4
-
G – frame stack22.5
-
H – effective top tube length26
-
I – wheel diameter20.8
-
J – head tube length5.5
-
K – handlebar length23.6
-
L – frame reach17.7
-
M – head angle70°
-
N – standover height18.8
Specification
Frame
-
Front: 6061 aluminum Rear:A356 Steel
-
HeadsetNeco H510
-
ForkCoil suspention fork, 40mm travel, is disc mount
-
Front wheelRim: MD-260 20*2.5""*36H*13G A/V | Spoke: 13G*171MM/172MM | Hub: MS-37F 13G*36H*100mm
-
Rear wheelRim: MD-260 20*2.5""*36H*13G A/V | Spoke: 13G*133MM/134MM | Hub: 48v 500w Himiway Hub Motor
-
TiresInnova 20x2.40 lA-1283
-
Battery48V15AH LG 21700 IP65 720Wh
-
Motor500w Himiway brushless gear motor
-
DisplayHimiway LCD Display
-
ThrottleThumb throttle
-
SensorsTorque sensor丨speed sensor丨brake sensor
-
CranksetCrank arm:6061-T6 145mm | Chain ring: 44T narrow wide steel chainring BCD104
-
CassetteShimano MF-TZ500-7 14-28T
-
ChainKMC Z8.3 EPT 100L
-
GroupsetShimano altus M310 7 speed
-
Front brakeNutt JAK-8 mechanical disc brake
-
Rear brakeNutt JAK-8 mechanical disc brake
-
RotorsF:160mm R:160mm
Components
Stem
-
Folding stem, riser length: 360mm
Himiway flip seatpost 27.2*300
Saddle
Himiway TTZ032X
Pedal
Aluminum pedal
Lights
48V LED light
Kickstand
Aluminum kickstand
Range
70 miles
Controller
48V/18A
Charger
US standard 2.0 A smart charger
Rider height
5'~6'
Weight
60.6 lb.
Max payload capacity
300 lb
